USB Output - Total 142W Max

USB-C Output: 100W Max

(5V3A,9V3A,12V3A,15V3A,20V5A)

USB-A1 Output: 18W Max

(5V3A,9V2A,12V1.5A)

USB-A2&A3 Output:12W Max

(5V2.4A)

Helper in the dark

5 Modes: Weak/Medium/Strong/SOS/Burst

10W Wireless Charging (x2)

5V1A,9V1A

√ DC Input: DC5525 Port; 12-30V,8A,182W Max

Three charging methods

1.Adapter (Package included): 26V 6.92A 179.92W

(for wall charge:Approx 6.8h)

2.Car Charger(Package not included):8A Max

(for 12V car:Approx 12.9h,for 24V car:Approx 6.8h)

3.Solar Panel (Package not included):12-30V, 8A, 182W Max

300W recommend(≥303W Solar Panel:Approx 6.8h)

√ USB-C Charging: 100W Max (Approx 12.3h)

USB-C Cable/plug package not included

√ DC Input(Adapter/24V Car/300W Solar Panel) + USB-C Charging

# All output port of QE02D can be used while charging #

 FAQ:

Q1: What devices can use FF Flashfish QE02D?

A1:
Notice:
Rated power: The maximum output power that a mechanical device can achieve.
Peak power: The maximum power that can be achieved in a short period of time, usually only for about 30 seconds.

About the AC output:
1. Only electrical appliances with a total rated power of less than 1200w can be started (such as TVs, stereos, laptops)
2. It can only be started when the total starting power is less than 2400w.
Appliances with motors need to take into account peak power (instantaneous power at start-up).
Such as refrigerators, soybean milk machines, air pumps, vacuum cleaners, printers, etc. Their peak power is generally "rated power *3 or *5". (for reference only; actual peak power: please refer to the equipment manual, or consult the equipment seller)

DC Output - Total 136W Max

DC5525*2 / Car Charger*1 : 13.6V 10A, 136W Max

USB Output - Total 142W Max

USB-C Output: 100W Max (5V3A,9V3A,12V3A,15V3A,20V5A)

USB-A1 Output: 18W Max (5V3A,9V2A,12V1.5A)

USB-A2&A3 Output:12W Max (5V2.4A)

###
Once exceeded, the plant will be in protection mode. We need to charge it with a wall charger to reset it. (Multiple activations: full charge + full discharge)
If it exceeds the protection threshold too much, it may burn the fuse, and then burn the machine. It is recommended that you confirm the rated power and starting power of the device before plugging it in.

Q2: How to calculate the working time for your devices?

A2:
1. AC output working time=1008wh * 0.9/the power of your device
For example, assume your power of device is 400W, working time will be 1008wh * 0.9/400w=2.3 hrs ( rough calculated )
2.DC and USB output working time=1008wh * 0.95/the power of your device
